At present, with the developed technology, perfect quality and lofty prospect, Beston plastic to oil machine for sale that also can be called waste plastic pyrolysis plant has already been widely used in some foreign countries and is highly praised by foreigners. Because our machine can not only deal with the problem of waste plastic but also protect the environment, turn waste into wealth and benefit to humanity.
Advantages of Plastic to Oil Machine for Sale
1. The waste plastic to oil conversion machine is equipped with casing, pressure gauges, thermometers, vacuum pumps, safety valves, emergency vent valves, explosion-proof valves, automatic alarming system and automatic slag system and so on, all of which can guarantee that everything goes well.
2. The casing installed outside the pyrolysis reactor can protect people’s body from burn and by the way extend the life of the reactor.
3. The pressure gauges and thermometers show the pressure and temperature at any time to avoid happening something.
In a word, if there is something wrong, the automatic alarming system equipped with the convert plastic to oil plant will alert you in the first time.
The entire process is sealed and do not flow out any exhaust gas; the flue condenser can improve the effect of removing dust; the four-layer dust removal systems can purify exhaust gas in the reactor to reach the standard of emission; non-liquefied combustible gas was purified by hydroseal, and then heat main furnace.
* High output: you can use the combustible gas to reheat the reactor to save energy and raise yield; the oil condenser of plastic to oil machine has large areas to improve the cooling efficiency and the rate of production; you can also add chemical catalyst supplied by us to speed up the reaction to increase the output by 20%.
* High quality: Beston all waste plastic recycling plants have got the CE, ISO, SGS certifications and uses automatic submerged arc welding technology and ultrasonic non-destructive testing. All the materials we use are stainless steel with high temperature resistant and corrosion resistant.
* High efficiency: the reactor can continue working; feeding while discharging; the efficiency of continuous plastic to oil machine produced by us is superior to all kinds of machines.
Applications of final products from plastic to oil Plant
* Oil: it can be used as fuel or reprocessed into diesel or gasoline by Beston oil distillation plants. Furthermore, we can burn it in the industry or sale it.
* Carbon black: the carbon black can be sold directly by you or made into carbon brick by briquetting plants. Moreover, you can reprocess it into high quality carbon by carbon brick grinding machines.
* Combustible gas: it can be as fuel to heat reactor of the waste pyrolysis plant or be recycled to use in industry or agriculture.
Types of Beston plastic to oil conversion equipment
Beston with its professional techniques has made six types of equipment for sale and these machine can be divided into three working methods: batch, semi-continuous and full-continuous. Different kinds of machines for converting of waste plastic have their special features and fictions. Please look at the following information:
|Working method||Batch||Semi-continuous||Fully continuous|
|Raw materials||Waste tire, plastic, rubber, oil sludge, medical waste|
|Reactor size||D2.2*L 5.1m||D2.8*L6.2 m||D2.8 *L7.1 m||L12.5*W2.2*H2.5m|
|Pattern||Horizontal & rotary||Not rotary type|
|Heating materials||Charcoal, wood, fuel oil, natural gas, LPG, etc.|
|Total power||24 kw/h||30 kw/h||54 kw/h||53.6kw/h||62kw/h||84kw/h|
|Floor area (L*W*H)||20*10*10 m||25*15*10 m||25*15*10 m||20*15*10m||33*15*10m||33*15*10m|
|Operating pressure||Normal pressure||Constant pressure|
|Cooling method||Water cooling|
|Service life||5-8 years|
Main equipment of waste plastic to oil machine
Waste plastic contains a little water in normal condition, and it must effluence the output. Therefore, waste plastic will be through a dryer to steam the moisture. If waste plastic is too big, plastic to oil machine can be equipped with a crusher to make big waste plastic into small pieces.
1. Reactor is the most important part of waste plastic to oil machine for sale with high temperature resistance and good stability, and it is to convert waste plastic to oil. In the process of conversion, there will also be both oil and carbon black generating.
2. Manifold of waste plastic or tyre pyrolysis plant is equipped with the machine that turns plastic or tyre into oil. It can separate heavy particles, gas oil and light oil. There are draining valves on the bottom of manifold to drain heavy particles. Light oil and gas oil are discharged into condenser by the out of tube on the top.
3. Oil condenser is a key component of plastic to oil equipment, Its fictions are to exchange heat and cool the high temperature oil gas that is from manifold. Outside the straw, the cold water absorbs the heat of oil gas and liquefies it.
4. Hydroseal is to remove sulfur and impurity and purify non-flammable gas. In the water tower, the water can be used about 7 days. The most important fictions is to prevent gun back to fire and ensure the safety of production.
5. Dust removal system in the plastic to oil conversion machine is to reduce the temperature of smoke and dust. The cooled smoke and dust is introduced to water tank and then through three steps: the impacting of water, the adsorption of Boer magnetic and water spray, which can reach the standard of emission.
How to convert plastic to oil?
1. Pyrolysis: the pyrolysis process reacts in the reactor, in which there is vacuum with high temperature and high pressure. It often needs 8-10 hours. The reactor whirls with double helix. The waste plastic will release the combustible gas and melt into oil gas and liquid carbon black. At this time, the temperature of reactor can reach about 350℃.
2. Cooling: it needs 2-3 hours and aims to get oil and improve the generation of oil. The Beston plant is equipped with the flue tube condenser, which has large cooling areas to cool oil gas, so you can get much fuel oil in short time. It really enhances the efficiency.
3. Discharging: it needs about 2-3 hours. Our plastic to oil conversion machine for sale will discharge automatically because it is installed automatic discharging system. The liquid carbon black will flow into slag pot and the oil gas will get into manifold. At this moment, the temperature is about 100℃ and it also needs 2-3 hours. the whole process id sealed.
4. De-dusting: it can reduce the pollution and protect the human beings’ health. In fact, it also corresponds to the policy of national protection-environment. The plastic to oil machine for sale has four-layers dust removal systems, and they are washing, magnetic adsorption, activated carbon and water spray. By them, the concentration of exhaust gas can be decreased to reach European standard of emission.
In addition to waste pyrolysis plant, there is also waste recycling plant for sale. Beston Machinery’ idea is to convert waste into energy and make the world more beautiful. If you also want to live a happy life and make much money, the waste plastic to oil machine for sale is the best choice for you. Let us take action quickly.
If you want to know more, please send an order.
